24-channel Electronic Granulator
Electronic granulator
The bottle stopper device on the bottle feeding track of the bottle conveying mechanism will transfer the bottle from the upper equipment to the bottling position, waiting for bottling. Through the vibration of the feeding corrugated board, medicines enter the warehouse in an orderly manner. The counting photoelectric sensor is installed in the warehouse. The medicine falling into the warehouse is quantitatively counted by the photoelectric counting sensor, and then filled into the bottle at the bottling position
1 |
Applicable bottle type |
· 10-500ml round, square plastic bottle |
2 |
Filling object |
00 ~ 5 # capsule, soft capsule, 5.5 ~ 20 Φ tablet, special-shaped pieces, sugar pill, Φ 3 ~ 12 pills |
3 |
Capacity |
20 - 90瓶/分钟 (related to the bottle specification, volume and drug specification) |
4 |
· Bottle quantity setting range |
1 - 9999 |
5 |
Power supply and power |
AC220V 50HZ 0.6KW |
6 |
Accurancy |
大于99.5% |
7 |
Gas Source |
0.6Mpa |
8 |
Dimensions |
1800×1400×1680mm |
9 |
Weight |
360kgs |
