定制货币紫外线塑料注射器消毒柜
产品描述
H-GMS-B系列热风循环隧道灭菌烘箱采用电加热为热能，电加热元件产生的能量利用热风循环烘箱加热烘箱内100级洁净空气。
对流瓶内的空气交换循环后，需要将热量传递给灭菌瓶，在排除空气或室内饱和湿热的同时不断供应新鲜空气，从而实现灭菌瓶的干燥。本机由不锈钢网带输送机组成。瓶子是在传送带过程中;瓶体通过空气加热和层流循环，达到杀菌干燥的效果。
将瓶内低温预热至冷却后，再进行高温灭菌，完成瓶的整个灭菌过程。其中，在空气的热杀菌段，高温热空气经风机过滤器经强风净化后，形成一个循环。
因此净化瓶在净化百热空气时，在风压作用下快速均匀循环。干燥消毒后，必须防止外界空气，湿热空气中的水分通过飞机的排气口进入飞机。其中，烘箱内空气的加热部分是一个加热循环。内置温度测量点，可根据需要设定并自动调节控制。
主要参数
瓶子的大小 |
60/100/125ml |
灭菌温度 |
350℃ |
灭菌时间 |
≥5分钟 |
网络速度 |
50 - 250毫米/分钟 |
网络的宽度 |
500毫米 |
净化等级 |
100年净化 |
冷却方法 |
气冷式 |
前层流风机 |
2500m³/ h，风压385 ~ 303pa |
权力 |
380 v 50赫兹 |
维 |
3500 * 1800 * 2300毫米 |
重量 |
4000公斤 |
权力 |
50千瓦 |
超声波功率 |
4千瓦 |
主要特点
1.采用液晶显示、触摸屏(PT)和可编程逻辑控制器(PLC)控制。2.3.加热机、运行等工艺参数由可编程逻辑控制器精确控制。机器变频风量可设定为自动平衡。如果房间门被大开，压力发生变化，进入风机后，排风机自动调整频率至压力，如果仍不能保持压力平衡，排气阀关闭，防止外界空气侵入。4.具有参数显示、分段显示、电脑自动打印记录和故障报警等功能。防止外界空气进入设备，确保工作室内保持百态灭菌。6.采用链轮本体传动网络，消除了一般网络容易产生偏差的缺陷。 Belt material uses 316 stainless steel. 7.This series of models to YY0217.3-2005 pharmaceutical industry standards, the GMP standard indicators 8.Oven equipped with seven pressure tables, separately for each section of high efficiency filter, the room with the cooling section, with the high temperature section of the cooling section and one hundred high-temperature protection section of the air pressure detection section. 9.Equip with DOP Authentication port on the box, enabling customers to verify. 10.Uniform heat distribution within the oven, sterilization temperature to ensure the segment ± 5 ℃. 11.FH value control exact, if not reach the sterilization temperature and sterilization time, the oven automatically stop, the machine runs with traceability. A failure storage function, the resulting failure to run the machine has auto-save feature. And record the causes of failure, time and exclusions. 12.Temperature changes during the production process can be recorded and stored, to facilitate viewing and on file at any time. Print data in two ways: multi-point temperature recorder curve with print. Display time of temperature curve is 30 milliseconds and precise control. 13.With a pressure balance system, using electric contact pressure table control and display, the oven can accurately control the pressure balance of the cabinets. 14.Equip with seven electrical contacts pressure table, control the pressure and all the various sections of a single high efficiency filter is equipped with a pressure differential table. Accurate control each pressure, each high-pressure filter equipped with pressure table, accurate control efficient filter. 15.Tunnel oven a full set of high efficiency filters adopt embedded installation, the both side of filter used hinge clamp is very easy to replace and install, filters on both sides with leak detection, leak monitoring device. In the region maintain continuous to 100 laminar flow, the filter specifications using the international standard specifications of the filter. 16.Hot-air cycling fan and high efficiency filters can be temperature> 400 ℃ 17.Insulation materials use silicate, heat insulation section thickness 150mm, shell temperature below 40 ℃. 18.Has “duty" fan function. 19.Tunnel oven belt equips with ultrasonic cleaning in line. 20.Touch screen has three password-protected.
