Electronic counting machines
Product Description ofTablet Counting Machine
SED-48S Automatic Electronic counting machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc. This machine adopts 48 sets imported counting sensor for counting with 48 guiding way and 4 heads.
The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by Easy Adjust wheel. The machine comes with Touch screen for easy operation.
Machine Parameters ofTablet Counting Machine
Model Name |
SED-48S |
Application |
1. Filled capsule(00-5#) 2. Soft Gelatin capsule 3. chewing gum 4. tablet 5. other solid object under machine range |
Hopper Volume |
110L |
Capacity |
10-140bottles/min(30-100pcs/bottle) |
Filling Quantity |
2-9999pcs/bottle (adjustable) |
Bottle Size |
Diameter: ≤50mm Height:40-180mm |
Power supply |
220V 50Hz(Can be customized)1.6KW |
Compressed air |
0.6Mpa 5L/min |
Machine Weight |
900kg |
Machine Size L × W × H (mm) |
2160*1530*1700mm |
Product Show ofTablet Counting Machine
Feature ofTablet Counting Machine
Strong compatibility, it can count and bottle various solid preparations or solid particles such as tablets (including special-shaped tablets), capsules, soft capsules (transparent and non-transparent), and pills.
Vibration discharge: 48 vibrating and gentle feeding, the special patented flap part filling system, the medicine is uniform and stable without damage.
Anti-high dust: Using the anti-high dust photoelectric sensing technology exclusively developed by our company, it can work stably in high dust environment.
Accurate counting: automatic counting by photoelectric induction, the bottling error is less than the national standard.
High degree of intelligence: it has a variety of alarm control functions such as no bottle, no counting, automatic fault detection and so on.
Auxiliary function: photoelectric induction automatic detection of no bottle and automatic shutdown.
Easy to operate: With intelligent design, various operation data can be set as required. 10 groups of setting parameters can be stored for use.
Easy maintenance: After simple training, workers can easily operate. Components can be easily removed, cleaned and replaced without any tools.
Application of Tablet Counting Machine
It can pack all kinds of tablets and capsules (transparent or opaque hard capsules, soft capsules, pills, etc.) in the range of 3-12 mm.Meet the requirements of GMP, suitable for scientific research
institutions, hospitals, small and medium-sized pharmaceutical factories, health products factory production packaging
