Semi-Automatic 8S Bottle Blow Molding Machine
Product description
The semi-automatic 8S blow molding machine sealing production line is a special aseptic packaging technology that can run continuously, filling medical polyethylene (PE) or polypropylene (PP) particles into the container, fully automatic filling and sealing process, fast Continuous production cycle;
It integrates multiple manufacturing processes in the same equipment, and completes the entire process of blowing, filling and sealing plastic containers in a single process under aseptic conditions, which can effectively ensure product safety.
The equipment has low production and management costs, good aseptic stability, high intrinsic quality of the finished product, and low possibility of cross-contamination. It can be widely used in the production of plastic-packaged terminal sterilized products and sterile products.
main parameter
No. |
Name |
Model/Specification/material |
Quantity |
1 |
Air cylinder |
Festo |
1 |
2 |
One-way throttle valve |
Festo |
2 |
3 |
Linear bearing |
MISUMI |
4 |
4 |
Oil-free bushings |
MISUMI |
5 |
5 |
Gear |
MISUMI |
1 |
6 |
Rack |
SUS440C |
2 |
7 |
Drag chain |
IGUS |
1 |
main features
1.采用时间压力灌装方法。该灌装time can be set to one thousandth of a second, with high filling accuracy and no mechanical wear.
2. The equipment is equipped with Class A air shower device. The filling and sealing parts are protected by aseptic air in the aseptic filling area to avoid external air pollution.
3. The servo motor is used to drive the needle up and down, which not only can effectively control the movement accuracy of the needle, but also provides a basis for replacing products with different specifications in the future.
4. Adopt the new design concept of standardization, modularization and general machine, only need to replace molds and parts, you can produce products of different specifications on one equipment.
5. Automatic customized online cleaning and disinfection system (CIP / SIP) and online integrity test of filters, humanized touch screen interface operation;
6. Stable process control, in line with GAMP5, 21CFR Part11 requirements.
7. BFS system solutions provide customers with the overall delivery of engineering design, equipment manufacturing and verification services.
