Automatic electronic laundry beads counting machine adopts 10 sets imported counting sensor for counting with 10 extra widen guiding way and one head.
Automatic Electronic Laundry Beads Counting Machine
产品Overview of Tablet Counter Machine
We have an excellent reputation for offering a wide range of capsule counting and filling machines. This product is manufactured using only quality tested materials.
We are a manufacturer of capsule counting and filling machines. Counting Discs: Professional 36” diameter. Discs on single fill models. Each disc is custom designed and manufactured to meet your
individual filling requirements. These remarkable machines are versatile enough to count any shape and size Coated uncoated tablets, hard or soft capsules, eg pear-shaped, oval and round.
Machine Parameters of Tablet Counter Machine
Model Name |
SED-10S |
Application |
1.Filled capsule(000-5#) 2.Soft Gelatin capsule 3.chewing gum 4.tablet 5.other solid object under machine range |
Hopper Volume |
50L |
Capacity |
20-50bottles/min |
Filling Quantity |
2-9999pcs/bottle (adjustable) |
Bottle Size |
Diameter: 30-100mm Height:40-180mm |
Counting Size |
Pills with diameter of 37 or less are compatible with 000-5 capsules soft capsules with diameters of 3.5-37 plain tablets special-shaped tablets sugar-coated tablets |
Compressed air |
0.6Mpa 3.5L/min |
Machine Weight |
320kg |
Machine Size L × W × H (mm) |
1360*1530*1700mm |
Feature of Tablet Counter Machine
(1) Strong compatibility, it can count and bottle solid preparations or solid particles such as tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), and pills;
(2) Vibration feeding: 10 vibrating uniform feeding, special patented laminating mechanism, discharging, uniform and stable discharging, no damage to medicine;
(3) High dust resistance: The company's original anti-high dust photoelectric sensing technology is used, which can work stably in high dust conditions;
(4) The special structure of the leak nozzle can prevent the drug from being blocked, and the vial with the bottle mouth can also be quickly filled (optional)
(5) High degree of intelligence, with multiple detection and alarm control functions such as no-bottle counting and fault self-checking;
(6) Function matching: automatic detection of no bottle photoelectric sensor, automatic shutdown
(7) Simple operation: intelligent design, various operating parameters can be set as needed
产品Show of Tablet Counter Machine
Application of Tablet Counter Machine
This machine adopts the most advanced anti-high dust electronic counting technology. Tablets (including fixed tablets), hard capsules, soft capsules (clear, opaque) pellets, and other solid particles ranging in size from 3 to 12 mm can be counted and dispensed. Can be bottled, boxed and bagged.
